LP200, LP250 & LP250W-MT PARTS LIST
LP200, LP250 & LP250W-MT REPAIR KITS
ITEM PART DESCRIPTION QTY
1 07759 Crankcase 1
2 13000 Oil filler Plug Assy. 1
4 06085 Crankcase Cover 1
5 07104 O-ring, Crankcase Cover 1
6 07186 Oil Sight Glass 1
7 07187 Gasket for Sight Glass 1
8 06086 Oil Dipstick Assy 1
9 01009 O-Ring, Dipstick Assy. 1
10 01010 Cylinder Screw 4
11 01011 Spring Ring 5
12 07109 Plug 1
13 07182 Gasket 1
14 07111 Bearing Cover 2
15 07112 Radial Shaft Seal 2
16 07113 O-Ring 2
17 07114 Hexagon Screw 8
20 07116 Taper Roller Bearing 2
20A 07117 Fitting Disc 1-3
20B 13001 Fitting Disc 1-3
21 07118 Shaft Protector 1
22 13242 Crankshaft 1
23 13243 Woodruff Key 1
24 13340 Connecting Rod Assy. 3
24A 13227 Hex Screw 3
24B 13278 Spring Washer 3
25 13341 Crosshead / Plunger Assy. 3
28 13232 Crosshead Pin 3
29A 07125 Centering Sleeve 3
29B 13220 Plunger Pipe (LP200) 3
29B 13022 Plunger Pipe
(LP250, LP250W-MT) 3
29C 07131 Tension Screw 3
29D 07755 Copper Ring 3
30 07789 Flinger 3
31 07133 Oil Seal 3
35 13196 Seal Sleeve (LP200) 3
35 13024 Seal Sleeve
(LP250, LP250W-MT) 3
36 13228 Leakage Seal (LP200) 3
ITEM PART DESCRIPTION QTY
36 13360 Grooved Ring (LP250) 3
36 13025 Leakage Seal (LP250W-MT) 3
37 07170 Seal Case 3
38 07140 O-Ring 3
38A 12055 O-Ring 3
39 13197 Pressure Ring (LP200) 3
39 13026 Pressure Ring
(LP250, LP250W-MT) 3
40 13115 V-Sleeve (LP200) 6
40 13027 V-Sleeve
(LP250, LP250W-MT) 6
41 13198 Support Ring (LP200) 3
41 13028 Support Ring
(LP250, LP250W-MT) 3
41 06702 Sleeve Support (LP255) 3
42 07173 Tension Spring 3
43 13029 Valve Casing 1
44A 07150 O-Ring 9
44B 06266 Support Ring for O-Ring
(LP250W-MT only) 3
45 06078 Compression Spring
(LP250W-MT) 3
46 07060 Valve Assembly 6
46A 07064 Valve Seat 6
46B 07063 Valve Plate 6
46C 07062 Valve Spring 6
46D 07066 Spacer Pipe 6
48 07156 Plug 3
48 06077 Plug (LP250W-MT) 3
49 07157 Stud bolt 8
49A 07158 Hexagon Nut 8
49B 07159 Disc 8
50 07423 Plug 1
50A 07161 Copper Ring 1
52 13020 Disc for Crankshaft 1
53 13021 Hexagon Screw 1
54 13321 Plug, 1” BSP 1
55 13322 Plug 1-1/2” BSP 1
Plunger Packing Kits
LP200 # 9307
Item Part # Description Qty.
36 13228 Leakage Seal 3
38 07140 O-Ring 3
38A 12055 O-Ring 3
40 13115 V-Sleeve 6
LP250, LP250W # 9308
Item Part # Description Qty.
36 13360 Grooved Ring 3
38 07140 O-Ring 3
38A 12055 O-Ring 3
40 13027 V-Sleeve 6
LP250W-MT # 9308-MT
Item Part # Description Qty.
36 13025 Leakage Seal 3
38 07140 O-Ring 3
38A 12055 O-Ring 3
40 13027 V-Sleeve 6
Valve Kit
# 09196
Item Part # Description Qty.
46A 07064 Valve Seat 1
46B 07063 Valve Plate 1
46C 07062 Valve Spring 1
