Parts list – Generac 5500EXL User Manual
Page 17
Generac Portable Products 5500EXL Extended Life Generator
17
PARTS LIST
Item Part #
Qty. Description
1
A92432
1
CRADLE
2
A92531
1
SUPPORT, Engine
3
A92731
1
SUPPORT, Engine & Muffler
4
92247
1
HOUSING, Engine Adapter
5
92678G
1
ASSEMBLY, Rotor
6
94980A
1
ASSEMBLY, Stator
7
65791
1
BEARING
8
67451
1
WASHER, Special Flat - M8
9
22129
16 WASHER, Lock - M8
10
86307
4
HHMS, 5/16-24 x 3/4
11
28092
1
HHCS, 5/16-24 x 9-1/4
12
92609
2
MOUNT, Vibration
13
82857
4
MOUNT, Vibration
14
92532
1
BRACKET, Muffler
15
90239
1
GASKET, Muffler
16
66476
2
CAPSCREW, M6 - 1.0 x
12mm
17
A7433
1
MUFFLER
18
40976
2
SCREW, M8 - 1.25 x 20
19
83083
1
SCREEN, Spark Arrester
20
81917
1
PIN, Roll 4mm x 10
25
66825C
1
CARRIER, Rear Bearing
26
74908
4
TAPTITE, M5-0.8 x 10
27
86308A
4
BOLT, Stator M6-1 x 145mm
28
65795
2
RECTIFIER, Battery Charge
29
66849C
1
TAPTITE, M5-0.8 x 30
30
67022
1
GROMMET, Rubber
31
84132
1
ASSEMBLY, Power Regulator
32
66386
1
ASSEMBLY, Brush Holder
33
66849
2
TAPTITE, M5-0.8 x 16
34
B67025
1
COVER, Bearing Carrier
35
22769
1
WASHER, Shakeproof Int. #10
36
86494
1
SCREW, M6-1.0 x 16 Wing
37
86292
1
HHCS, - #10 Self Driller
38
77395
4
NUT, Flange Lock - M6
39
83465
4
GROMMET, Tank
40
57058
4
HHCS, M6-1.0 x 55
41
80270
1
VALVE, Tank
42
78299
1
BUSHING, Tank
43
B4363
1
CAP, with Gauge, Fuel
44
B1695
1
TANK, Fuel 7 Gal.
45
B92039
1
SHIELD, Heat
Item Part #
Qty. Description
46
92665
1
INSULATION, #2-1/4" Thick
47
85000
1
CLIP, Insulation
48
14353621 1
WIRE, Ground
49
26850
2
LW, EXT, Shakeproof M6
51
92982
1
DECAL, Danger
52
96057
2
DECAL, Heat Shield
55
25244
12 NUT, 5/16-18 Hex
57
96058
1
DECAL, Control Panel
58
92630
1
ASSEMBLY, Control Box
59
NSP
1
ENGINE
60
22531
2
HHCS, 5/16-18 x 1-3/4"
61
22142
2
SCREW, 5/16-18 x 3/4"
62
77282
1
SWITCH, Starter
63
22287
2
SCREW, 1/4 - 20 x 3/4
64
22097
2
LOCKWASHER, M6
65
22127
2
NUT, 1/4 - 20 Hex
66
78289
1
BRACKET, Starter Switch
67
93826
1
DECAL, Start Instructions
68
B96068
1
SHIELD, Heat
69
56893
5
CRIMPTITE, 10-24 x 1/2
70
B2153
8
SCREW, #12 Self Drill
71
22473
4
WASHER, Flat M6
Parts Not Illustrated:
37806
1
125V 30A Locking plug
43438
1
240V 30A Locking plug
72347
1
Spark plug
73111
1
Air cleaner element
84882
1
Spark plug wrench
20820
1
Owners manual
65787
1
Battery charge cable
Battery Tray Components:
22129
2
Lockwasher, M8
45771
2
Hex nut M8
96925
1
Battery tiedown
96924
2
J-bolt
15453621 1
Battery cable, positive
15553621 1
Battery cable, negative
96923
1
Battery tray
22145
2
Flat washer
58443
4
Screws, battery tray
