IP camera
Installation and configurations
Hardware Installation
Figure 5. Installation diagram
•
Plug the Ethernet cable into the RJ-45 connector at the LAN connector as picture
shown.
•
Plug the other end of the Ethernet cable into any available LAN port. A typical
E t h e r n e t
Power
