English, Board layout – GIGABYTE GeForceTM FX 5200 Graphics Accelerator GV-N52128D User Manual
Page 5
Hardware Installation
- 5 -
English
2.2. Board layout
TV-out
VGA Monitor
Connector
(15pin)
DVI-I Connector
NTSC / PAL TV
Projector
Analog LCD Monitor
Analog Monitor
OR
VGA Output
AV Output
S-VideoOutput
Analog LCD Monitor
Digital LCD Monitor
DVI Output
DVI-I to D-Sub Connector
VGA Output
TV-Out
VGA Monitor
Connector
(15pin)
DVI-I Connector
1) GV-N52128D
