Page 5
2. When the ROBO PLAY (29) button is in the ON position (the ROBO
PLAY INDICATOR illuminates RED), starting the sampler mutes the
selected source. When the sample ends, the source automatically
turns back on.
BATTERY BACKUP: The PDM-24s is equipped with battery backup to
retain samples. To activate this feature, a 9 volt battery (not included)
needs to be connected to the BATTERY HOLDER (42) located on the
rear panel. This will enable you to store samples in memory, and when
the unit is unplugged, the battery backup will retain the samples for
future use. If the unit is unplugged with no battery attached, all the
samples will be lost.
LOW BATTERY INDICATOR: A low battery indicator is included with the
PDM-24s. When changing the battery, make sure the unit is plugged in
and the power is ON. Failure to adhere to this will result in lost memory.
The low battery indicator is ON when the selected memory bank LED
blinks. The LED will also blink if no battery is connected to the unit.
Specifications
INPUTS:
DJ Mic....................................................1.5mV 2Kohm balanced
Phono.........................................................................3mV 47Kohm
Line.......................................................................150 mV 27Kohm
OUTPUTS:
Main/Booth......................................................0 dB 1V 400ohm
Max..............................20V Peak to Peak
Rec...........................................................................225mV 5Kohm
MIC 1 & MIC 2:
DJ Mic....................................................1.5mV 2Kohm balanced
Bass......................................................................................± 12dB
High.......................................................................................± 12dB
GENERAL:
Frequency Response....................................20Hz - 20KHz +/- 2dB
Distortion................................................................................0.02%
S/N Ratio...............................................................better than 80dB
Talkover Attenuation..............................................................-16dB
Headphone Impedance.........................................................16ohm
Power Source.............................................115/230V 50/60Hz 10W
Dimensions.....................................................19”w x 4”h x 9”d
Weight........................................................................10.17 lbs
