Gefen Repeater For HDMI 1.3 GTV-HDMI1.3-141 - Manual (Page 7)

4
4
PANEL LAYOUT
Front Panel
Front Panel
Back Panel
Back Panel
HDMI Output
HDMI Output
HDMI Input
HDMI Input
Power LED
Indicator
Power LED
Indicator
5V DC
Power Input
5V DC
Power Input
PANEL LAYOUT
