11

thermostat as shown in Figures 10 and 11.
Goodman® part number CHT18-60 is a single-stage cool and
single-stage heat thermostat.

Goodman® part number HPT18-60 is a single-stage cool,
two-stage heat pump thermostat. The first stage is heat pump
heating and the second stage is optional electric heat.

If additional features are desired, such as digital or program-
mable capabilities, these thermostats are commercially avail-
able. Follow the thermostat manufacturer’s instruction for in-
stallation.

Start-Up Procedure

Prior to start-up, ensure that all electrical connections
are properly sized and tightened.

All panels must be in place and secured. For Air Tight
application, neoprene gasket must be positioned at pre-
scribed locations to achieve 2% leakage.

Tubing must be leak free.

Unit should be elevated, trapped and pitched to allow
for drainage.

Low voltage wiring is connected.

Auxiliary drain is installed when necessary and pitched
to allow for drainage.

Drain pan and drain tubing has been leak checked.

Return and supply ducts are sealed.

Unit is elevated when installed in a garage or where
flammable vapors may be present.

Unit is protected from vehicular or other physical dam-
age.

Return air is not obtained from any areas where there
may be objectionable odors, flammable vapors or prod-
ucts of combustion such as carbon monoxide (CO),
which may cause serious personal injury or death.

Regular Maintenance

HIGH VOLTAGE!
Disconnect ALL power before servicing or
installing this unit. Multiple power sources may
be present. Failure to do so may cause property
damage, personal injury or death.

The only item to be maintained on a regular basis by the user
is the circulating air filter(s). Filter should be cleaned or re-
placed regularly. A certified service technician must perform
all other services.

NOTE: DO NOT USE THESE DIAGRAMS FOR AEPF
MODELS. SEE INSTALLATION AND OPERATING
INSTRUCTIONS SPECIFICALLY FOR AEPF MODELS.

0.1"

0.2"

0.3"

0.4"

0.5"

1

700

670

650

595

510

2

820

785

765

745

705

ASPF183016

3

920

900

850

840

815

4

1075

1055

1015

975

960

5

1130

1115

1085

1040

1000

1

1060

865

600

515

420

2

1105

910

795

745

690

ASPF303616

3

1165

1070

1020

960

915

4

1285

1240

1195

1140

1100

5

1435

1395

1350

1315

1265

1

1060

865

600

515

420

2

1105

910

795

745

690

ASPF313716

3

1165

1070

1020

960

915

4

1285

1240

1195

1140

1100

5

1435

1395

1350

1315

1265

1

1445

1275

1175

940

855

2

1545

1405

1325

1260

1145

ASPF426016

3

1660

1610

1555

1490

1415

4

1905

1870

1810

1750

1695

5

2115

2070

2000

1965

1915

CFM deliverd against External Static Pressure

Model

Motor

Speed Tap

Table 13
