7
Know your product
Before using the Reciprocating Saw, familiarise yourself
with all the operating features and safety requirements.
Use the tool only for the applications intended. All other
applications are expressly ruled out.
10
1. Trigger switch
2. Pendulum control
3. Lock-off button
4. Tool-free blade clamp
5. Pivoting shoe
6. Saw blade 7. Rotatable rear handle
8. Handle rotation release switch
9. Speed control dial
10. Shoe adjustment screw (x 2)
11. Hex key
12. Blade clamp lever
6 5 4 12 2 8 1 3
9 7
11
