1 0G0056 1 RTR-2390--35KD1 CPL
0F9677 1 RTR-2390--45KD1 CPL
2 0G0057 1 STR-2390--35AD1 CPL
0F9664 1 STR 390 45K 2P 1PH DIRECT
0G0058 1 STR-2390--35KD1 CPL
0G0184 1 STR 390 45KW 2P 3PH 480V
0G0059 1 STR-2390--35GD1 CPL
0G0183 1 STR 390 45KW 2P 3PH 208V
3 0C9708 REF INSTR HYPOT TEST (NOT SHOWN)
4 SEE ENGINE EV REF ENGINE ADAPTER
5 SEE ENGINE EV REF FLEXPLATE
6 0F5767B 1 ASSY FLYWHEEL CPL W/40MM FAN B
7 0E5706 1 REAR BEARING CARRIER 390/DRCT
8 0F7874 1 ASSY BRUSH HOLDER 390/HSB
9 0F6124 1 GUARD REAR BEARING CARRIER CPL
10 038150 4 WASHER FLAT #8 ZINC
11 023454 1 KEY WOODRUFF #E
12 077043F 1 CONDUIT FLEX 1-1/4" (30” LG)
13 04576100BU 4 STUD M14-2.0 570 G5 ZINC
14 052646 4 WASHER FLAT M14
15 043123 4 WASHER LOCK M14
16 051779 4 NUT HEX M14-2.0 G8 YEL CHR
17 0A2601 1 SCREW HHC M16-2.0 X 45 G8.8
18 0A2602 1 WASHER FLAT .688 ID X 3.25 OD
19 0F3398 4 SCREW SHC M10-1.5 X 16 G10.9
20 046526 4 WASHER LOCK M10
21 0C3993 4 SCREW HHTT M4-0.7 X 25 BP
22 022264 4 WASHER LOCK #8-M4
23 * 047248 1 BALL BEARING-45 MM
24 * 070892 1 SLIP RING MACHINED
* ROTOR REPLACEMENT PARTS
