To provide head support for a smaller child, your swing
model may include one of the following accessories:
Two head supports:
Insert them into the pockets in
the back of the cloth seat pad.
Head support cushion:
Use it in the seat as shown,
threading the seat belt straps
through the corresponding holes
in the cushion.
Using the Tray
Step 1.
Unlatch the tray by squeezing
the two latches under the tray
at the same time, and lift up.
Be careful not to let the tray
hit your baby when lifting or
closing the tray.
Step 2.
To latch tray, push it down firmly.
If tray does not latch, check back brace to be sure the word
“REAR” is away from the seat.
Attaching the Seat Belt
Reclining Back—
Four Positions
Pull adjustment wire upward
and pull seat backward to
recline seat. Extra pressure is
required to go from the third
position to full recline.
For upright position, simply lift
back of seat forward.
Tray must be latched at all times when
baby is in swing. Pull up on tray to be sure it is latched.
Attaching the Seat Cover
Step 1.
With baby out of swing,
open the battery compartment
lid by inserting a coin (penny,
nickel or dime) into the coin
slot. After the lid pops open,
swing it down and remove it.
Step 2.
Insert four “D” cells. CHECK
that the batteries are put in
correctly. Your swing will not
run if the batteries are put in
backwards.
Step 3.
To replace lid, put the two
tabs of the lid into the two
slots in the bottom of the
motor housing. Swing lid up,
and press it into place until
you hear the latch click.
Coin
slot
Installing the Batteries Using the Head Supports
(on certain models)
Back of cloth seat pad
Step 1.
Thread one end of the seat
belt through the belt retainer
as shown.
Step 2.
Thread both ends of seat belt
through the buckles as shown.
CHECK that the belt is threaded
correctly by pulling on the seat
belt. The belt should not slip
through the buckle.
To release, push in on front
of buckle.
Step 1.
Slide the pocket of the seat
cover over the top of the seat
as shown.
Step 2.
Pull the crotch strap and both
ends of the seat belt through the
slots in the seat cover.
Step 3.
Push the elastic loop through
the hole on one side of seat.
Step 4.
Fold cover around bottom of
seat. Then fasten the hook into
the elastic loop on one side as
shown. Repeat on other side.
CAUTION: Be sure the seat
cover at armrest does not
interfere with tray latching.
Using the Swing
Step 2.
Fasten the seat belt. Adjust
belt as needed to get a snug
fit around your child.
Step 3.
Close the tray. CHECK that
the tray is latched by pulling
up on the tray.
Do not
depend on the tray or seat
belt alone to hold your baby.
Always secure your baby
with both the seat belt and
tray when your child is in
the swing.
CHECK that all parts are securely fastened together
before using the swing.
Step 1.
Open tray and seat belt. Place baby in the seat.
Mix ’N Move™ Toy System
Your swing is equipped with two toys in Graco’s Mix
’N Move™ interchangeable toy system. This system,
featured on various Graco ® swings, highchairs, strollers
and mobile entertainers, allows your baby to enjoy a
changing array of amusements and even take favorites
along. Look for other toys in the enclosed leaflet.
Step 1.
To install a toy, insert the two
prongs on the toy base into a toy
mount at the notches.
Step 2.
Turn toy base one quarter
turn until you feel the toy
snap into place.
Check that toy is firmly
inserted by pulling on
the toy.
Toy is removable (turn it the other way with a little
pressure) so that you can replace it with other toys
when desired.
If you choose not to use the toys at this time, please
insert the two plastic covers as described below to fill
the holes in the tray.
To Install Covers
To insert a cover into the tray of
your swing, first push one side
into a notch, then push in the
other side.
To Remove Covers
Remove child from swing
before removing covers.
With the aid of a flat head
screwdriver, carefully pry up one
edge of a cover until it comes off.
Throw the covers away
immediately; they are not
reusable.
