Tracer 2000 DVR user manual
Version 3.0 Page 8 of 36
CHAPTER III
INSTALLATION
FRONT PANEL VIEW
REAR PANEL VIEW
Power supply
Parallel port
BNC connector
GPIO
VGA
USB Ports x 2
10/100 Ethernet
MIC and Speaker
Alarm
Menu
Display
Playback
Confirm
Removable Air
Filter Bracket
Removable Air
Filter Bracket
Remove and clean up Air Filters monthly is essential.
IR
UP
LEFT RIGHT
DOWN
COM1
COM2
Audio
