POWER SUPPLY (EXTERNAL):
Power Input Voltage: 12VDC
Power Consumption: 6.5 Watts typical
Dimensions:
10.3in H x 0.8in W x 3.3in D(262mm x 20mm x 84mm)
Weight:
0.5lb. (0.25 kg)
LED INDICATORS, Unit:
PWR: Steady on when power applied.
COL: Common collision indicator, for the 100Mbps and 10Mbps
domain
LED INDICATORS PER RJ-45 PORT:
100: Steady on when speed is 100Mbps
LK/RK: Steady on when LINK is operational, flashing for receive
activity
Agency Approvals
UL listed (UL1950), cUL, CE
Emissions meet FCC Part 15 Class A
NEBS compliant, certifiable as part of a cPCI system
Warranty
Three
years, return to factory
Made in USA
