Appendix - 67 -
English
Step 3:
If RAID 0 is selected, you'll have to decide whether you want the RAID array to be created automatically
or manually (Figure 5). Use <1> or <2> key to select. (We do not suggest that you select <2> Manual
Create unless you know well how to set every required item, like block size.)
Step 4:
If you wish to proceed to map and stripe all current data and future data to the RAID disks, press .
Or press to perform striping on future data only. Then press (Figure 6).
SiS RAID BIOS Setting Utility
RAID Setup
* Current Created Raid *
RAID 0
<1> Auto Create <2> Manual Create : 1
[Q] : Exit current menu
Location Model Capacity Mode RAID Type
Disk 1 ST3120026AS 111GB UDMA 6 Single
Disk 2 ST3120026AS 111GB UDMA 6 Single
SiS RAID BIOS Setting Utility
RAID Setup
* Current Created Raid *
RAID 0
Split the SOURCE (Disk 1) data to RAID disks? N
[Q] : Exit current menu
Location Model Capacity Mode RAID Type
Disk 1 ST3120026AS 111GB UDMA 6 RAID0
Disk 2 ST3120026AS 111GB UDMA 6 RAID0
Figure 5
Figure 6
