A-9
Exploded View List
1. Hinge Pin
2. Left Endcap
3. Shroud
4. Handle
5. Warming Rack
6. Cast Iron Cooking Grates
7. Flavorizer ® Bars
8. Cooking Box
9. 1/4-20 keps nut
10. Slide Out Bottom Tray
11. Work Surface
12. Catch Pan Holder
13. Left Trim Rear Assembly Arm
14. 1/4 - 14 x 5/8 inch bolt
15. Left Trim Piece
16. Left Trim Front Assembly Arm
17. 1/4 - 20 x 2-1/4 inch bolt
18. 1/4 - 20 x 1 inch bolt
19. Nylon Washer
20. Caster Frame
21. Caster
22. Bottom Rack
23. Wheel
24. Hubcap
25. Hair Pin Cotter
26. Right Endcap
27. Thermometer
28. Handle Hardware
29. Control Panel Knobs
30. Control Panel
31. Control Panel Hardware
32. Crossover ® Ignition Button
33. Crossover ® tube
34. Front / Rear Burner
35. Manifold Hardware
36. Manifold, Hose and regulator (assembled)
37. Catch Pan
38. Disposable Drip Pan
39. Wing Nut
40. Igniter
41. Top Frame Assembly
42. Fuel Gauge
43. Wrap-Around Trim Piece
31. Control Panel Hardware
44. Right Trim Piece
45. Cylinder Glides
46. Wheel Frame
47. LP Tank
48. 1/4 - 20 x 1 3/4 inch bolt
