Problem

Cause

Corrective Action

Excessive Noise

Wheel Rubbing Inlet

Adjust wheel and/or inlet cone. Tighten wheel hub or bearing
collars on shaft.

V-Belt Drive

Tighten sheaves on motor/fan shaft. Adjust belt tension. Align
sheaves properly (see page 4). Replace worn belts or sheaves.

Bearings

Replace defective bearing(s). Lubricate bearings. Tighten
collars & fasteners.

Wheel Unbalance

Clean all dirt off wheel. Check wheel balance, rebalance in
place if necessary.

Low CFM

Fan

Check wheel for correct rotation. Increase fan speed.*

Duct System

See page 3.

High CFM

Fan

Resize ductwork. Access door, filters, grills not installed.

Duct System

Change obstructions in system. Use correction factor to adjust
for temperature/altitude. Resize ductwork. Clean filters/coils.
Change fan speed.*

Static Pressure
Wrong

Duct system has more
or less restriction than
anticipated

Check rotation of wheel. Adjust fan speed.

High Horsepower

Fan

Check rotation of wheel. Reduce fan speed.

Duct System

Resize ductwork. Check proper operation of face and bypass
dampers. Check filters and access doors.

Fan Doesn’t Operate

Electrical Supply

Check fuses/circuit breakers. Check for switches off. Check for
correct supply voltage.

Drive

Check for broken belts. Tighten loose pulleys.

Motor

Assure motor is correct horsepower and not tripping overload
protector.

Overheated Bearing

Lubrication

Check for excessive or insufficient grease in the bearing.

Mechanical

Replace damaged bearing. Relieve excessive belt tension.
Align bearings. Check for bent shaft.

NOTE: Always provide the unit model and serial numbers when requesting parts or service information.
* Always check motor amps and compare to nameplate rating. Excessive fan speed may overload the motor

and result in burnout.

Troubleshooting

8

455308 • SWB / SFB / SFD, Rev. 7, March 2013

Copyright 2013 © Greenheck Fan Corporation

As a result of our commitment to continuous improvement, Greenheck reserves the right to change specifications
without notice.

Specific Greenheck product warranties are located on greenheck.com within the product area tabs and in the
Library under Warranties.

Greenheck Centrifugal Utility Fan catalog provides additional
information describing the equipment, fan performance,
available accessories, and specification data.

®

Phone: 715.359.6171 • Fax: 715.355.2399 • Parts: 800.355.5354 • E-mail: [email protected] • Website: www.greenheck.com

Our Commitment

AMCA Publication 410-96, Safety Practices for Users and
Installers of Industrial and Commercial Fans, provides
additional safety information. This publication can be
obtained from AMCA International, Inc. at www.amca.org.
