APPENDIX A BLOWER PERFORMANCE TABLES
BELT DRIVE
HIGH STATIC HORIZONTAL
CPC/H036 HIGH STATIC BELT DRIVE HORIZONTAL
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.6 1742 0.50 1431 0.36
0.8 1626 0.52 1357 0.39 1078 0.27
1 1611 0.56 1315 0.42 1011 0.28
1.2 1605 0.62 1299 0.46 976 0.31
1.4 1605 0.68 1281 0.51 959 0.35
1.6 1281 0.57 981 0.41
1.8 981 0.47
CPC/H048 HIGH STATIC BELT DRIVE HORIZONTAL
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.6 2056 0.72 1721 0.54
0.8 1996 0.77 1662 0.57 1328 0.40
1 1924 0.79 1603 0.61 1270 0.43
1.2 1952 0.88 1559 0.64 1210 0.44
1.4 1888 0.92 1543 0.70 1195 0.49
1.6 1557 0.77 1180 0.54
1.8 1192 0.60
CPC/H060 HIGH STATIC BELT DRIVE HORIZONTAL
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.6 2323 0.92
0.8 2315 1.00 2009 0.77
1 2308 1.09 1992 0.84 1666 0.60
1.2 2338 1.21 1992 0.92 1646 0.66
1.4 2359 1.32 2025 1.02 1648 0.72
1.6 2404 1.45 2056 1.13 1684 0.82
1.8 2088 1.24 1722 0.92
CPC/H072 HIGH STATIC BELT DRIVE HORIZONTAL
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.6 2746 1.38 2515 1.12
0.8 2721 1.47 2494 1.21 2261 0.97
1 2689 1.56 2500 1.32 2255 1.06 1994 0.83
1.2 2752 1.74 2473 1.40 2252 1.15 1996 0.91
1.4 2802 1.88 2487 1.53 2286 1.27 2037 1.02
1.6 2553 1.67 2308 1.40 1997 1.08
1.8 2355 1.51 2014 1.19
2.0 2055 1.29
NOTES:
ESP, In
H
2
O
TURNS OPEN
0 1 2 3 4 5
ESP, In
H
2
O
TURNS OPEN
0 1 2 3 4 5
ESP, In
H
2
O
TURNS OPEN
0 1 2 3 4 5
Tables represent dry coil without filter, to compensate for filter add 0.08" to measured E.S.P.
SCFM correction for wet coil = 4 %.
ESP, In
H
2
O
TURNS OPEN
0 1 2 3 4 5
