GB - 8
TOOLS REQUIRED
• Adjustable wrench
• Petroleum jelly or dielectric grease.
UNPACK UNIT
Remove unit and all other components from
the shipping container. Engage transmission
bypass lever (see Moving The Unit Manually
on page 11). Push unit from container onto a
level surface. Disengage transmission
bypass lever.
FIRST TIME USE
1. Install steering wheel.
2. Connect negative battery cable to
battery. See Battery Removal and
Installation on page 18 and perform step
1 in the removal section and perform
steps 3, 4, and 6 in the installation
section.
3. Check engine oil. Refer to Engine
Manual.
4. Check tire pressure (see Specifications
on page 25).
5. Fill fuel tank (see Filling Fuel Tank on
page 10).
6. Adjust seat (see Seat Adjustment on
page 11).
7. Check safety interlock system (see
Safety Interlock System on page 9).
8. Check level and pitch of mower deck
(see Leveling Mower Deck on page 15
and Adjusting Mower Deck Pitch on
page 15).
9. Check function of all controls (see
Operation on page 9).
1. Seat
2. Steering Wheel
3. Ignition Switch
4. PTO Switch
5. Throttle Lever
6. Parking Brake
7. Forward and Reverse Pedal
8. Mower Deck
9. Discharge Chute
10. Mower Lift Lever
11. Fuel Tank
ASSEMBLY
WARNING: AVOID INJURY. Read
and understand the entire Safety
section before proceeding.
CONTROLS AND FEATURES
Figure 3 OA0016
1
4 3
5
6
2
7
10
8 9
11
