Your digital box

Front view

Rear view

- +

LNB IN

Signal In

from LNB on satellite

LNB OUT

This

has no function and
does not act as a loop
through

SPDIF

Digital

Audio Out con-
nection

ETHERNET

For future

use (Broadband connec-
tion required)

HDMI

High

definition output
(For connection
to a HD Ready
TV)

VCR

Standard

definition SCART
output (For
connection to a
recording device)

RS232

For

factory use
only

Standard definition

SCART output (For connection
to a non HD TV or recording
device)

STANDBY

Power On/

Standby.

VOL +/-

Volume

up and down.

CH +/-

Channel up

and down.
