18" & 20" Super Heavy-Duty Bandsaws -9-
SECTION 4: CONTROLS AND
COMPONENTS
Figure 4. Rear view of bandsaw.
Identification
The 18" and 20" Super Heavy-Duty Bandsaw
controls and components are frequently referred
to in this section. Please take the time to identify
the following controls. Their locations are shown
in
Figures 4 and 5:
1. Electrical Junction Box
2. Guide Post Handwheel
3. Blade Guard
4. Guide Post Lock Knob
5. Blade Tracking Handknob
Figure 5. Front view of bandsaw.
6. Upper Blade Guide Assembly
7. Fence
8. Control Panel
9. Blade Tension Handwheel
10. Emergency Stop
11. Blade Tensioning Scale
10
6
9
7
8
11
1
5
4
3
2
