EDID MANAGEMENT
EDID Mode Selection
1. EXTERNAL
MODE:
To use this mode, move the EDID switch to the Ext position. See page 8 for
details on using the External EDID.
2. INTERNAL
MODE:
To use this mode, move the EDID switch to the Int position. This mode
will use a preset EDID, from the factory, that is stored in the Gefen 1:10
Splitter For HDMI 1.3. This pre-programmed standard EDID data structure is
compatible with most A/V display devices. All resolutions and audio formats
specifi ed in this EDID will be passed to the source device. See the tables
below for a complete listing of the resolutions and audio formats listed in this
EDID.
NOTE: All other HDMI devices/displays connected to the output ports must
be compatible with at least one resolution/audio format specifi ed in this
EDID. It is recommended to set, on the source device, a common resolution
and audio format shared by all attached devices/displays. This is to ensure a
compatible signal is output to all connected devices/displays.
Internal EDID Video Timings
Timing
Refresh Rate
Timing
Refresh Rate
1280 x 720p
50 Hz
720 x 576p
50 Hz
1280 x 720p
59.94 / 60 Hz
1920 x 1080p
50 Hz
1920 x 1080i
50 Hz
1920 x 1080p
59.94 / 60 Hz
1920 x 1080i*
59.94 / 60 Hz
1440 x 480p
59.94 / 60 Hz
720 x 480p
59.94 / 60 Hz
1440 x 576p
50 Hz
* Native Resolution
Internal EDID Audio Formats
Audio Format
Supported Channels
LPCM
2CH
AC-3
2CH / 5.1CH
DTS
2CH / 5.1CH
