THERMOSTAT* CONNECTIONS TO RH/VH HEAT PUMPS
WITH INDOOR BBA/BBC BLOWER COIL
Approved Thermostats: 1213403, 1213404, 1213410, 1213406
NOTE: 1. When installing accessories, wiring may have to be modified. Follow the instructions
in the accessory kit’s installation instructions.
WARNING
To avoid personal injury, shock or death, disconnect the
electrical power before electrically connecting any
equipment or changing any existing wiring.
R C/X Y O W2 E G
(1) (1)
Room Thermostat
Blower Coil
Remote Unit
R C Y O W2 E G
R C Y O W
