2
CONTENTS
The CAT5•7500HD system consists of:
--- (1) CAT5•7500HDS (Sender unit)
--- (1) CAT5•7500HDR (Receiver unit)
--- (2) 5 VDC power supply
--- (2) DVI cables (6FT)
--- (1) USB cable (6FT)
--- (2) PS/2 cables (6FT)
--- (1) Audio cable (6FT)
--- (1) Rack ears
--- (1) User Manual
HOW IT WORKS
In its most basic application, the CAT5•7500HDS Sender unit resides next to the com put er.
Supplied with the system, DVI cables, PS/2 keyboard, PS/2 mouse, audio, and USB cables,
they con nect the computer to the CAT5•7500HDS Sender unit.
The CAT5•7500HDR Receiver unit is placed next to the monitors, keyboard, mouse, and
USB peripherals at the remote location. The monitor and keyboard are connected to the
CAT5•7500HDR, similar to the way they are con nect ed to the back of the computer (PC
or Macintosh).
