Three view drawing – O.S. Engines FT-160 Gemini User Manual
Page 17
30
13.26cc x 2 / 1.218cu.in. x 2
27.7mm / 1.091in.
22.0mm / 0.866in.
2.000-10.000r.p.m.
1,100g / 38.8oz.
23.5
50.5
63.5
4 -5.2
56.5
196
54
68
120
76
THREE VIEW DRAWING
Dimensions(mm)
Specifications
Displacement
Bore
Stroke
PracticalR.P.M.
Output
Weight
C
Copyright 2004 by O.S.Engines Mfg. Co., Ltd. All rights reserved. Printed in Japan.
60090531 040501
TEL. (06) 6702-0225
FAX. (06) 6704-2722
6-15 3-Chome Imagawa Higashisumiyoshi-ku
Osaka 546-0003, Japan
URL : http://www.os-engines.co.jp
