6 Specifications
§ Frequency Response:
48Hz to 36kHz, +/- 3dB
§ Sensitivity:
89 dB 1 watt 1 meter
§ Min/Max Power (Tube):
75/500 watts per side
§ Min/Max Power (Solid State): 100/1000 watts per side
§ High Level Input Impedance:
4 ohms (Nominal)
§ HF Transducers:
Two Genesis 1” Circular Ribbon
Tweeters (front & rear)
§ Midrange Transducers:
One Genesis 5 “ titanium cone
midrange
§ Bass Transducers:
Two Genesis 6.5” aluminium
cone
§ Controls:
Upper Midrange Contour,
Tweeter level
§ Inputs:
High-level with 5-way binding posts
§ Outputs:
High-level with 5-way binding posts
§ Dimensions:
H 41 ¾ ” x W 10 ¼ ” x D 14”
§ Weight:
79 lbs (36kg) per side
