To connect an active subwoofer (eg Meridian M1500 or M2500)
3UBWOOFER
0(/./
'
35"
#2/33/6%2
).054
$)2%#4
).054
• Connect the SUB analogue output socket from the G61 Digital
Surround Controller to the subwoofer’s line-level input using a
phono lead.
Use RZ and LZ if you have two subwoofers.
The digital surround controller provides a very high-quality
crossover for the subwoofer, and for best results you should use
this instead of the subwoofer’s crossover. To do this remove any
crossover in the subwoofer or set it to its highest setting (eg
200Hz). The subwoofer crossover can be set from the front panel of
the G61; see Subwoofer crossover frequency , page 30.
I n s t a l l i n g t h e
d i g i t a l s u r r o u n d
c o n t r o l l e r
1 2
