Specifications
Current Probe 80i-500S
3
43
Current Probe 80i-500S
Safety Characteristics
Designed for measurements on 600 V rms Category III. Pollution degree 2,
double or reinforced insulation requirements in accordance with:
•
EN/IEC
61010-2-032
•
ANSI/ISA
S82
•
CSA-C22.2
No.1010.1-92
•
UL1244
Electrical Specifications
Current range ........................................................................ 1A to 500 A rms
AC current over range limit ..............................................................700 A rms
Maximum 10 minutes, followed by removal from current carrying
conductor for 30 minutes.
Output Signal............................................................................ 1mV AC/A AC
Accuracy
5 to 10 Hz
1 to 500 A .............................................................................-3 dB typically
10 to 20 Hz
1 to 300 A ..........................................................................................
±
5 %
300 to 400 A ....................................................................................
±
15 %
400 to 500 A ....................................................................................
±
25 %
20 to 45 Hz
1 to 500 A ..........................................................................................
±
5 %
45 to 65 Hz
1 to 20 A ...............................................................
±
5 % of reading + 0.3 A
20 to 100 A ........................................................................
±
5 % of reading
±
3
°
phase shift
100 to 500 A ......................................................................
±
2 % of reading
±
5
°
phase shift
65 Hz to 3 kHz
1 to 50 A ..............................................................................
±
(5 % + 0.4 A)
50 to 500 A ........................................................................................
±
5 %
Influence of temperature on accuracy ................... <0.15 % per 10
°
C (18
°
F)
Altitude
During operation .................................................................2.0 km (6560 feet)
While stored .....................................................................12 km (40 000 feet)
