Using your notebook
A26391-K183-Z121-1-7619, edition 1 37
Removing a PC card
With the symbol in the task bar you can stop the PC card:
► Click on the symbol with the left mouse or touchpad key.
► Select the PC card you want to stop and remove.
► Press the Enter key.
Wait for the dialogue box which tells you that it is now safe to remove the PC card.
2
1
► Press the eject button (1). The PC card will project further out of the notebook's case. If the
eject button is lowered, you must first cause the eject button to release from the notebook
casing. To do this, press the eject button until it releases.
► Slide the PC card out (2) of the notebook.
Integrated 56k modem
The integrated 56k modem supports all data communication applications, such as:
●
Modem operation: High-speed downloads at up to 56,000 bit/s (V.9x). Downward-compatible to
V.34 modems.
● Fax mode: Transmitting and receiving at up to 14,400 bit/s
● Simple country adaptation with programme
The modem complies with the EU Directive 91/263/EEC (Telecommunications terminal equipment
directive) and has been checked in agreement with the guideline TBR-21.
The modem can be operated in the following countries:
Multifrequency (MFC) dialling
Belgium, Denmark, Germany, Finland, France, Greece, Great Britain, Holland, Ireland, Iceland, Italy,
Luxembourg, Norway, Austria, Portugal, Sweden, Switzerland and Spain.
Pulse dialling:
Belgium, France, Holland and Italy.
Also in: Poland, Slovenia, South Africa and Hungary.
