Getting Started
Focus
1
1-9
Focus
Remove the lens cap, point the lens at the target, and manually rotate the lens
with your finger, as shown in Figure 1-5, until the image is in focus.
eii005.eps
Figure 1-5. Focusing the Camera
Set Temperature Level and Span
1. Press G as shown in Figure 1-6 to automatically set the camera’s
temperature level and span.
2. Press G again as needed to properly scale the image.
Level & Span
eii006.eps
Figure 1-6. Setting the Level and Span
