8
M60C User Guide
Specification
Audio Inputs
Unbalanced 775mV (nominal), gold plated phono
Balanced 3Vrms max, XLR
Power
Amplifiers Complementary bipolar design, with
output-stage error correction and twin loop
design
Tweeter 65W mean power
Mid + Bass 65W mean power
Bass 65W mean power
Distortion <0.05%, typically less than 0.01% up to
full power at all frequencies
Noise and hum < –94dBr
Acoustic
Output Typically > 108dB spl @ 1m
Noise < 15dB spl @ 1m
Frequency
response In room response within 3dB, 45Hz–
20kHz
Crossover Double Butterworth at 2.6kHz, First Order
at 400Hz
Drive units
Bass 2 x 160mm polypropylene high-efficiency
long-throw shielded custom drivers
Tweeter Meridian 25mm piston in short horn:
aluminium dome with silver voice-coil.
Cabinet Constructed from fine veneered MDF
Dimensions 195x670x280mm
Weight 20 kg each
Power 100–125; 200-230; 210–250V AC 50–
60Hz
10VA idle; 200VA max
