Installation instructions
Gas rate and injector size table
NATURAL GAS LPG
Test point pressure (kPa) 1.0 2.75
Burners Injector
orifice size
(mm)
Nominal
gas rate
(MJ/h@1kPa)
Injector
orifice size
(mm)
Nominal
gas rate
(MJ/[email protected])
CG604LC, CG604CWC, CG604DWFC, CG905DWFC
Auxiliary (right front)
0.85 3.6 0.55 4.0
Semi-rapid (left & right rear)
1.30 8.5 0.80 8.5
Wok (left front in CG604CWC,
CG604DWFC, left front &
centre in CG905DWFC)
1.75 15.0 1.00 13.5
Rapid (left front in CG604LC)
1.55 12.0 0.95 12.0
CG905DWAC
Auxiliary (right front)
0.85 3.6 0.45 2.7
Semi-rapid (left rear)
1.22 7.2 0.70 6.2
Wok (centre)
1.90 16.3 1.10 15.3
Rapid (left front & right rear)
1.45 10.5 0.85 9.3
