5. Configuring the FieldServer as a TIWAY Server
For a detailed discussion on FieldServer configuration, please refer to the FieldServer
instruction Configuration mM anual (Virtual PLC) . The information that follows describes how
to expand upon the factory defaults provided in the configuration files included with the
FieldServer (See “.csv” files on the driver diskette).
This section documents and describes the parameters necessary for configuring the
FieldServer to communicate with a TIWAY Client.
The configuration file tells the FieldServer about its interfaces, and the routing of data
required. In order to enable the FieldServer for TIWAY communications, the driver
independent FieldServer buffers need to be declared in the “Data Arrays” section, the
FieldServer virtual node(s) needs to be declared in the “Server Side Nodes” section, and the
data to be provided to the clients needs to be mapped in the “Server Side Map Descriptors”
section. Details on how to do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal value being the
default.
5.1. Server Side Connection Descriptors
Section Title
Connections
Column Title Function Legal Values
Port
Specify which port the device is
connected to the FieldServer
P1-P8
Protocol Specify protocol used TIWAY, TIWAY_BDLC
Baud* Specify baud rate
110 – 115200, standard
baud rates only
Parity* Specify parity
Even, Odd, None, Mark,
Space
Data_Bits* Specify data bits 7, 8
Stop_Bits* Specify stop bits 1
Handshaking* Specify hardware handshaking RTS, RTS/CTS, None
Server_Hold_Timeout*
Specifies time FieldServer will
reserve server side connection
while waiting for the Client side
to update data in Data_Array (if
necessary)
>1.0s
