Assembly
Fork Post
Fork Cover
• Insert the fork post up through the hole in the neck of the
frame. Make sure the fork is positioned so that the fork
covers face the rear wheels.
REAR OF
TRIKE
• Fit the handlebar front to the fork post.
Hint: The handlebar front is designed to assemble to the
fork post one way.
• Fit the handlebar back to the fork post and handlebar
front. Hold them together fi rmly.
• First, insert the remaining #8 x ¾" screws through the
outer holes in the handlebar back and tighten.
• Then, insert the #8 x 2¼" screw through the center hole
in the handlebar back and tighten.
Handlebar Front
¾" Screw
¾" Screw
2¼" Screw
Handlebar Back
9
10
Fork Post
5
