FS-8700-87 SDD16 Driver Manual Page 8 of 10
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]
4.4. Client Side Map Descriptors
4.4.1. FieldServer Related Map Descriptor Parameters
Column Title Function Legal Values
Map_Descriptor_Name
Name of this Map
Descriptor
Up to 32 alphanumeric
characters
Data_Array_Name
Name of Data Array where
data is to be stored in the
FieldServer One of the Data Array
names from “Data Array”
section above
Data_Array_Location
Starting location in Data
Array 0 to maximum specified in
“Data Array” section above
Function
Function of Client Map
Descriptor
RDBC
4.4.2. Driver Related Map Descriptor Parameters
Column Title Function Legal Values
Node_Name
Name of Node to fetch data
from
One of the node names
specified in “Client Node
Descriptor” above
Data_Type* Data type Flag
Length Length of Map Descriptor 1-16
Address Starting digital line number 0 – 15
4.4.3. Timing Parameters
Column Title Function Legal Values
Scan_Interval Rate at which data is polled >0.1s
