95-5025 DASH DISASSEMBLY
FORD MUSTANG 1987-1993
A
1
D isconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Using Metra's 86-5618, pull the
factory head unit from the dash and
disconnect the wiring. (Figure A) 2
3
Continue to kit assembly.
B
ALSO REMOVE (2) THREADED STUDS FROM UNDER BRACKET
7/16” (2)
HEX BOLTS
RADIO SUB-DASH BRACKET
Remove two 7/16” hex bolts from inside the dash cavity and remove the radio
sub-dash bracket. (See recommended tool list on front cover)
Note: The threaded studs from under this bracket will also need to be removed for
the aftermarket Double DIN radio to clear. (Figure B)
