22
HOW TO USE MENUS (Continued)
Others(1/2) Menu screen
Option
(1) DPMS
(2) Audio Input
(3) Screen Orbiter
(for RGB)
Function
Specifies time before
DPMS starts.
Can specify the background
color when specifying time.
Selects audio input terminal.
Sets up screen orbiter.
Operation
Display DPMS screen and press
or to select an option.
Use or for switching.
Can specify background by
setting time to other than Off.
Display the “Audio Input”
adjustment screen and use
or
to select an option.
Use or to switch between
available choices for the
selected option.
Display the “Screen Orbiter”
adjustment screen and use
or
to select an option.
Use or to switch between
available choices for the
selected option.
Range
Time
Off (disabled)/1 min./
15 min./45 min./60 min.
Background
Black/White
No Audio/Audio 1/Audio 2
Mode/Time
Off (disabled)
Time (every 1 hr)
Mode (every time mode is
switched)
Moving area
Min.(moves in small range)
Std.(moves in moderate
range)
Max. (moves in wide range)
Others Menu(See P. 30,34–38.)
Others Menu screen is divided into the following two screens.
Others(2/2) Menu screen
Option
(1) Video Input
(for Video)
(2) S-video Input
(for S-video)
(3) BNC Input
(4) D-SUB Input
Input Terminal Menu(See P. 30,33–34.)
Function
Selects video mode.
Selects video mode.
Selects BNC Input signal.
Selects D-SUB Input signal.
Operation
Use or for switching.
Use or for switching.
Display BNC Input screen
and press
or to select an
option.
Use or for switching.
Select Comp.video or Decoder
by Function to set up Mask.
Display D-SUB Input screen
and press
or to select an
option.
Use or for switching.
Select Decoder by Function to
set up Mask.
Range
Auto/NTSC/PAL/SECAM/
PAL60/N-PAL/M-PAL/
4.43NTSC
Auto/NTSC/PAL/SECAM/
PAL60/N-PAL/M-PAL/
4.43NTSC
Function
Comp.video/RGB-PC/
Decoder
Mask
Off/5/10/15 (dot)
Function
RGB-PC/Decoder
Mask
Off/5/10/15 (dot)
