open
3 /
8
(9mm)
gap between
panels
BEFORE YOU START
FOR INTEGRATED SINGLE MODELS DS603I
(NOTE: FOR DOUBLE MODELS, REFER TO BACK OF THIS BOOK)
S I N G L E
I N T E G R A T E D P A N E L P R E P A R A T I O N
part number 526608 J
06/2004
(page 1 of 6)
US
2x
HEIGHT OF THE PANEL
Measure door/drawer height (or equivalent) and write it in the first
box below, then complete the equation.
For example: 16” (407mm) 3 /
8
” (9mm) 15 5 /
8
” (398mm)
panel height
(15 5 / 8 ” (398mm) MIN)
Note: When the top of the has to be lower than the
adjacent cabinetry, the Panel can be increased in height.
PLEASE NOTE: Your model of may differ from the model shown in the diagrams. Diagrams have been simplified to enable clearer instruction.
FOLLOW THESE INSTRUCTIONS BEFORE REFERRING TO PRODUCT INSTALLATION INSTRUCTION SHEET P/N 526607.
WARNING!
The air vent between the Panel and the adjacent cabinetry must not
be covered. An air gap of
3 /
8
” (9mm) MUST be provided.
The Door of the
can be made to match your
kitchen cabinetry. This diagram,
with the addition of your own
measurements will help you
calculate the required panel
sizes.
Be sure the Product
is not plugged in.
WIDTH OF THE PANEL
Measure the width between adjacent door/drawer fronts and write it
in the first box below, then complete the equation.
For example: 24 1 /
4
” (616mm) 2 x 3 /
32
” (2.5mm) 24 1 /
16
” (611mm)
door clearance panel width
door clearance
( 3 /
32
” (2.5mm) MIN)
panel width
(23 7 /
16
” (595mm) MIN)
air gap panel height
