10
MB15C101
5. Do Outut Current
3.0
2.5
2.0
1.5
1.0
0.5
0.0
0 − 2 − 4 − 6 − 8 − 10 − 12
V
OH
(V)
I
OH
(mA)
V
CC
= 3.0 V, Ta =+ 25 ° C
V CC
= 3.0 V, Ta = +25 ° C
3.0
2.5
2.0
1.5
1.0
0.5
0.0
0 2 4 6 8 10 12
V
OL
(V)
I OL (mA)
S.G.
GND
V CC
V CC
50 Ω
1000 pF
fin
Do
OSCin
Parameter Analyzer
IOH
S.G.
GND
V
CC
V CC
50 Ω
1000 pF
fin
Do
OSCin
Parameter Analyzer
IOL
V
OH
– I
OH
V
OL
– I
OL
Measurement Circuit
