Assembly
• Place the mat, print side up, on a flat surface
• Fit both straps on each side of the mat down through
the slots in the supports. Make sure the tab on the end
of the strap forms a "T" under the support.
• “Snap” both tabs on the mat into the slots in
the support.
• Pull up on the mat to be sure it is secured to
the supports.
• Fasten the toucan and butterfly leaf to the straps on the
arch or palm tube.
• Fit the “T” strap on the arch through the slot in the
tiger. Make sure the tab at the end of the strap forms
a “T” through the slot.
• Fit the palm tube and the giraffe tube into the
openings in the supports, as shown.
Mat
Support
Giraffe Tube • Fit the ends of the long tube into the openings in the
supports, as shown.
Long Tube
Palm Tube
Tab
Strap
1
2
3
4
"T"Strap
