Appendix
Connector Designations
A
A-1
Appendix A
Connector Designations
A.1 Connector Designations
Terminal Designations, 960PS-200
Pin Description
1 GND
2 AC Line Voltage
3 AC Line Voltage
4 -15 @ 2 A
5 +15 @ 2 A
6 RETURN
7 +5 V Return Sense
8 +5 V@ 10 A
9 + 5 V SENSE
10 CHASSIS GND
Terminal Designations, 960PS-21 0
Pin Description
1 AC Line Voltage, Neutral
2 AC Line Voltage, Line
3 GND
4 V3, - 15 VDC
5 V2, +15 VDC
6 V4, +24 VDC
7 DC Common
8 DC Common
9 DC Common
10 V1, +5 VDC
11 V1, + 5 VDC
