Left-side panel components – FUJITSU V700 User Manual
Page 19
14 - Locating the Controls and Connectors
Figure 3. LifeBook notebook left-side panel
Left-Side Panel Components
The following is a brief description of your LifeBook notebook’s left-side components.
Optical Drive
The optical drive bay contains a Modular Dual-Layer Multi-Format DVD Writer. See “Optical Drive” on
page 56.
Optical Drive Release Button
The optical drive release button opens the optical drive.
Emergency Tray Release
The emergency tray release is used in the event you want to open the tray when power is not available.
See “Emergency Optical Drive Tray Release” on page 59.
Optical Drive Release Button
Optical Drive
Emergency Tray Release
