Insulated Gate Bipolar Transistor (IGBT)
Audiophile and powerful
Direct mode
The audio signal is directly amplified
High-pass, low-pass and band-pass
crossovers
Adjustable from 50Hz to 5kHz
Progressive controlled cooling system
Regulates the amplifier temperature
1
3
4
5
Pseudo-balanced input
No parasite
Controlled cooling system
Air flow control
Safety terminal
Cable and sheath complete integration
8
6
7
Symmetrical design
Audiophile quality
It makes the difference:
• Symmetrical design
• Remote control
• Direct Mode
• Stable into 1 Ohm stereo
• High-Cap Compatible
• Classe AB amplification (IGBT)
Technical characteristics:
CEA 2006 power (4 Ohms, ≤1% THD+N, 14.4 Volts): 2x155W
Nom. power: 2x200W into 2 Ohms with 0.04% THD
Nom. power: 2x300W into 1 Ohm with 0.05% THD
Nom. power (bridged mode): 1x410W into 4 Ohms with 0.03% THD
Nom. power (bridged mode): 1x600Winto 2 Ohms with 0.04% THD
Adjustable high-pass crossover from 50Hz to 5kHz
Adjustable low-pass crossover from 50Hz to 5kHz
Adjustable band-pass crossover from 50Hz to 5kHz
Direct Mode
Protections: short-circuit, direct current, thermal overload,
polarity reversal
