6
L i f e B o o k C S e r i e s N o t e b o o k B I O S
Serial ATA Port 0 Submenu of the Main Menu
The Serial ATA Port 0 submenu identifies what Serial
ATA/IDE devices are installed. Note that actual hard drive label shown may vary.
Depending on the drive type, information such as cylin-
ders, heads and sectors may also be displayed.
Figure 2. Serial ATA Port 0 Master Submenu
Menu Field Options Default Description
Type: n Auto
n None
[Auto] Select Auto to have the type of Serial or Parallel ATA device automatically identified
by the BIOS at POST. If None is selected, the following Set-up items do not appear.
LBA Format Logical Block Addressing (LBA)
Total Sectors: --- --- The total number of sectors on your hard disk
Maximum Capacity: --- --- The maximum capacity of your hard disk
PhoenixBIOS Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
Main
Item Specific Help
Select Serial ATA/IDE
drive installed here.
[Auto]
The BIOS auto-types the
drive on boot time.
[None]
The drive is disabled.
Serial ATA Port 0 [FUJITSU MHT2040BH-SATA]
Type: [ Auto ]
LBA Format
Total Sectors: 78140160
Maximum Capacity: 40008MB
▲
