Setting the standard for Precision
The quicker way for a cleaner cut
TS 55 EQ
Nothing beats the convenience of the TS 55 for cutting down panels. Big on power, small in size, the TS
55 makes quick work of sheet goods with greater accuracy and far more versatility than a panel saw.
When mated to a MFT/3 (Festool’s multifunction table), it rivals the precision and capability of most
table saws and miter saws.
TS 75 EQ
Turn to the TS 75 when you need more capacity. MMC electronics mean that your cuts will be burn‐free
and glue‐ready, even in thicker or stacked material. With 1600 watts of power and almost 2 ¾” of
cutting capacity, cutting three or four sheets of ply at one time is a breeze.
TS 55 EQ TS 75 EQ
Item # 561 174 561 188
Included in Package
High Quality Carbide Blade 48 tooth (491 952) 36 tooth (493 198)
Guide Rail Included 55” (1400 mm) 75” (1900 mm)
Slip clutch No Yes
Splinter Guard Yes Yes
Limit Stop Yes Yes
Plug‐it Power Cord Yes Yes
Systainer SYS 4 SYS 5
Specifications
Power Consumption 1200 watts / 10 amps 120v AC 1600 watts/ 13 amps 120 v AC
Saw Blade Speed 2,000 ‐5,000 rpm 1,350 – 3,550 rpm
Saw Blade Diameter 6 ¼” (160 mm) 8 ¼” (210 mm)
Bevel Cuts 0 ‐ 45 degrees 0 – 45 degrees
Cutting Depth on Rail 1 15/16” (55 mm) @ 90 degrees
1 7/16” ( 37 mm) @ 45 degrees 2 ¾” (70 mm) @ 90 degrees
2 1/8” (55 mm) @ 45 degrees
Cutting Depth without Rail 2 1/8” (55mm) @ 90 degrees 2 15/16” (75 mm) @ 90 degrees
Arbor Size .787” (20 mm) 1.101” (30 mm)
Weight 9.92 lbs. (4.5 kg) 13.6 lbs. (6.2 kg)
