3.11 Function Controls

The function controls (F1 and F2) work like
the auto-dialing feature of a telephone, auto-
matically executing the function assigned to
them. The function can be turned off by press-
ing appropriate function control again.

Default settings

F1: Shift (brief press) or Zoom (long press)

F2: Ring brilliance

How to register menu items

1. Press the [MENU] key.

2. Press [A/C SEA] (F1) or [A/C RAIN] (F2)

to open the function menu.

[ SETTING FOR F1 KNOB ]

SSel by omnipad & press ENT.S

EBL

OFFSET

SHIFT

ZOOM

RINGS

MODE

DISP

DATA

MARK
BRILL

NOISE

REJ

TRAIL

TONE

PULSE

LENGTH

CHARA

CTERS

NO

FNCTN

WPT

MARK

WATCH

MAN

CUSOR

POSITN

EBL
REF

GUARD

IN/OUT

NAV

TALKER

OWN

POSITN

DEAD

SECTOR

VECTOR
LENGTH

VECTOR

REF

OTHER

MENU

SHIFT/

ZOOM

ECHO
TRAIL

TRAIL

TIME

ALARM

LEVEL

PANEL

DIMMER

VRM

UNIT

HIS

TORY

COLLI

SION

AUTO

ACQ

ECHO

STRTCH

INT
REJECT

TRAIL

ON/OFF

TUNE

A/M

Figure 3-11 Function menu

3. Select function desired.

4. Press the [ACQ/ENTER] key.

5. Press the [MENU] key to close the menu.

3.12 Suppressing Noise

Electrical noise can be suppressed by turn-
ing on “8. NOISE REJ” on the OTHERS
menu.

3.13 Adjusting Brilliance of
Markers

“2. Mark Brill” on the OTHER menu adjusts
the brilliance of markers other than the head-
ing marker.

3.14 Outputting Target Position

Radar target position data can be output to a
navaid in IEC 61162 format. Select the radar
target with the cursor , and then press and
hold down the [TLL] key to output the data.
This function requires position data and head-
ing signal.

3.15 Dead Sector

When the scanner is installed at a close dis-
tance in front of the wheelhouse the radar
should be set not to transmit within that area,
to prevent microwave hazard. Ask your
FURUNO representative ordealer to provide
this feature.
