Fisher-Price L3891 - Manual (Page 5)

Assembly
• Insert two #10 x 2,2 cm black screws through the
footrest and into the seat bottom. Tighten the screws.
Insert Screws Here
6
Hinge
• Turn the seat assembly face down.
• Insert the hinge rod through the hinge on the seat back
and seat bottom, as shown.
• Insert a #10 x 2,2 cm black screw into the hinge rod.
Tighten the screw.
• Set the seat assembly aside for Assembly step 10.
Hinge Rod
• Turn the seat bottom assembly upright.
• Fit the seat back pins into the slots in the top side of the
seat bottom assembly.
Seat Back Pins
Slot Slot
Frame Leg
7
• Pull the frame leg out on each frame to open. Make sure it
"clicks" into place.
