Friedrich MR12C1F User Manual
Page 5
C I R C U I T D I A G R A M
Models :
MW09C1F / MR09C1F
MW12C1F / MR12C1F
Fan Motor
Controller PCB
Power
Relay
Overload
Relay
Compressor
Power
Supply
Compressor
Capacitor
SW
Power Circuit
Thermistor
(outdoor temp.)
Fan Motor
Stepping
Motor
Thermistor (room temp.)
Baristor
Terminal
SW
Power Circuit
Thermistor (pipe temp.)
Display
Board
Controller PCB
BLACK or GRAY
BLACK or GRAY
4
2006.03.13
