SPECIFICATIONS

Inputs (Interlaced)

Format NTSC/PAL

Auto Detect

Composite(BNC) 1vpp

S-Video

Y - 1v pp
C -286mv pp

Component (SMPTE)(BNC)

Y—1vpp

Interlaced (480i)

Cr—700mv pp
Cb - 700mv pp

RGB

Comp. Sync—1vpp
RGB-700mv pp

HD/PC Pass-Thru

D15M

Remote Control “D9F”

RS-232 ASCII

Outputs (Progressive)

R,G,B (BNC or DB15)

700mv pp, TTL Sync

YprPb

700mv pp, Sync on Y-1vpp

RGsB

Gs - 1vpp
RGB - 700mv pp

D15F

Pin Function

1

1

Red Out

1

2

Green Out

1

3

Blue Out

1

7

Red Gnd

1

8

Green Gnd

1

9

Blue Gnd

10

Sync Gnd

11

Sync Gnd

13

H Sync Out

14

V Sync Out

Horizontal Sync:

NTSC: 31.5KHz, 37.7KHz, 45KHz, or 48KHz- depending on model
NTSC: 63KHz - Native Rate Series Plus only
PAL: 31.2KHz, 37KHz, 40KHz - depending on model
PAL: 53KHz - Native Rate Series Plus only 4.0 vpp TTL

Vertical Sync:

60Hz/50Hz, 4.0 vpp TTL

Composite Sync :

4.0 vpp TTL

Dimensions

13D X 17.25W X 4.24H (with feet) (Depth includes rear BNC)

Weight

15lbs, 20lbs shipping

Power Consumption

24w with 120v, 33w with 220v

Power Supply

100-240VAC 50/60Hz Auto Ranging

9
