Parts picture – Fisher-Price P5921 User Manual
Page 5
Note: Some parts shown are assembled on both sides of the vehicle. This illustration shows assembly on left side only.
5
PARTS PICTURE
2
Parts Not Shown:
Label Sheets
#10 x ¾" Trusshead Screw
#6 x 1" Screw - 2
#10 Lock Nut
1
Vehicle
2
Hubcaps - 4
3
Seat
4
Steering
Bracket
5
Steering Wheel Assembly
6
Steering Wheel Cap
7
6 Volt Charger
8
6 Volt, 4 Amp/Hr Battery
3
1
5
6
8
4
7
P6830a-0920
