MPF50S SERIES PORTABLE FILTRATION SYSTEMS
CHAPTER 7: PARTS LIST
7-2
Item
Part #
Description
1
823-6231
Pan, Filter
2
806-
5223SP
Base Assembly (Includes items 3 & 4)
900-9542
Bracket, Motor-Mount – All MPF50S
900-1748
Brace, End- Filter Base
900-8585
Brace, Rear Cross- Filter Base
3
810-2805
Caster, 2"- Swivel (Without Brake)
4
810-2806
Caster, 2"- Swivel (With Brake)
5
809-0475
Screw- 10-32 x 5/16 Hex
6 900-3751 Bracket,
Standoff
7
900-8825
Screen, Filter Paper Support
*
803-0003
Paper, Filter 17 ¾” x 12 ½” 100 sheets
*
803-0002
Powder, Filter, 80 packets
8 823-0889 Ring,
Hold-down
9
230-2836
Lid, Filter Pan
10
810-3162
Handle, Pan Lid 802-
*
826-1379
Screw, #10 x ½" Phillips (Lid Handle) (Qty. of 10)
*
809-0184
Washer, Lock - #10 (Lid Handle)
*
809-0020
Nut, Cap- 10-24 (Lid Handle)
11
106-7847
Complete Hose/wand assembly
* 810-3303 Hose
12
Motor, Filter Pump
826-1712
115V 60HZ 1/3 HP (Includes Motor and Gasket)
826-1270
230/240V 50/60HZ 1/3 HP (Includes Motor and Gasket)
13
826-1264
Pump, Filter - 4GPM (Includes Pump and Gasket)
14
813-0265
Nipple, ½ x 2-½" NPT BM
15
813-0062
Elbow, ½" NPT BM
*
806-3844
Heater Strip, 120V 40W
*
806-7435
Heater Strip, 230/240V 70W
16
813-0165
Elbow, Street- ½" NPT BM
17
813-0022
Nipple, ½" x Close NPT BM
18
810-1435
Flexline, ½ x 12" S/S Hose
19
813-0545
Union, ½ x ½" Flexline Hose
20
807-1219
Receptacle, 115V 3-Wire (120V Domestic Units Only)
*
807-1224
Cord, Power - 3-Wire 115V
*
807-4317
Cord, Power – Euro 3-Wire 230/240V
21
910-8587
Panel, Outer - Left Side
22
910-8586
Panel, Outer - Right Side
23
910-3788
Holder, Power Cord
