Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box Description
14 30A** ABS module power
15 — Not used
16 30A** Blower motor
17 — Not used
18 40A** PCM
19 — Not used
20 — Not used
21 30A** Starter solenoid
22 30A** ABS motor
23 — Not used (fuse plug)
24 30A** Wiper relay
Relay 01 Mini Relay Wiper HI/LO
Relay 02 Mini Relay Wiper park
Relay 03 Mini Relay Coil-on-plug and HEGOs
Relay 04 Mini Relay Heated wiper park relay
Relay 05 Mini Relay Auxiliary coolant pump (V8 engines)
Relay 06 Mini Relay Horns
Relay 07 — Not used
Relay 08 Mini Relay A/C clutch
Relay 09 — Not used
Relay 10 Standard Relay Blower motor
Relay 11 Standard Relay Wipers
Relay 12 — Not used
Relay 13 — Not used
Relay 14 Standard Relay PCM
Relay 15 Standard Relay Starter motor
Diode — Not used
*Mini fuses **Cartridge fuses
Roadside Emergencies
153
